MASW / VS30 Shear Wave Velocity Testing in Stoke-on-Trent

Stoke-on-Trent sits on a patchwork of ground conditions that make seismic site classification trickier than most developers expect. We regularly encounter former colliery backfill, deep bands of glacial till, and pockets of soft alluvium along the Trent tributaries. A standard borehole log will not tell you the shear wave velocity profile, yet that profile is exactly what determines your site class. The MASW survey fills that gap. We run a linear array of geophones at the surface, record surface-wave dispersion, and invert the data to produce a one-dimensional Vs profile. That profile feeds directly into the Vs30 calculation required by BS EN 1998-1:2004. For sites near the Hanley ridge or down in the valley floor, the difference in Vs30 can shift the design spectrum by an entire site class. The seismic microzonation work we have done across the Potteries shows just how locally that variation plays out.

On Stoke-on-Trent's reclaimed colliery land, a single Vs30 number from a desk study can overestimate stiffness by an entire site class. MASW gives the measured value, not an assumed one.

Our service areas

Methodology and scope

At 53.026 degrees north, Stoke-on-Trent sits within a low-to-moderate seismicity region, yet the ground response can amplify modest bedrock motions when the near-surface materials are soft. We see that most clearly on brownfield plots where historical mining has left a legacy of uncompacted fill. The MASW method records Rayleigh-wave energy using a 24-channel seismograph and a sledgehammer source. Processing extracts the fundamental-mode dispersion curve, which is then inverted with a genetic algorithm or a damped least-squares routine to get the Vs column. The Vs30 value comes from the harmonic mean of the top 30 metres. What makes Stoke-on-Trent unusual is the velocity inversion we sometimes find: a stiff layer of lodgement till overlying weaker coal-measure mudstone. That inversion can go unnoticed with conventional SPT correlations, which is why we often pair MASW with a few SPT drillings to ground-truth the contact depths and confirm the interpretation. The output includes Vs versus depth plots, a Vs30 classification per NEHRP and BS EN 1998, and a site-specific elastic modulus estimate for foundation design.

MASW / VS30 Shear Wave Velocity Testing in Stoke-on-Trent — Technical reference — Stoke-on-Trent

Local geotechnical context

The most common geotechnical surprise in Stoke-on-Trent is the thickness of made ground. Historical maps show opencast workings and marl pits that were backfilled with whatever was available, often colliery shale, ash, and brick rubble. That material can be five to fifteen metres thick, with Vs values below 180 m/s. A building designed on the assumption of a Site Class C profile may be under-designed if the true Vs30 pushes the site into Class D or even Class E territory. The consequence is a higher elastic response spectrum ordinate and larger base shear demand on the structure. The BS EN 1998-1 framework multiplies the design ground acceleration by the soil factor S, and moving from Class C to Class D raises that factor notably. On sloping sites along the Trent escarpment, we also check whether the lateral variation in Vs could produce differential ground motion across the footprint, a condition that becomes relevant for long-plan buildings and bridge abutments. A targeted MASW survey on the actual footprint removes the guesswork and gives the structural engineer the correct spectral parameters.

Need a geotechnical assessment?

Reply within 24h.

Email: info@geotechnical-engineering.biz

Reference standards

BS EN 1998-1:2004 (Eurocode 8: Seismic design), BS 5930:2015 (Code of practice for ground investigations), BS EN 1997-2:2007 (Eurocode 7: Ground investigation and testing)

Technical data

Parameter	Typical value
Method	MASW (Multichannel Analysis of Surface Waves)
Measured parameter	Shear wave velocity (Vs) vs depth
Key output	Vs30 (time-averaged velocity over 30 m)
Applicable standard	BS EN 1998-1:2004, Eurocode 8
Seismograph channels	24 (vertical geophones, 4.5 Hz)
Source type	Sledgehammer on aluminium strike plate
Typical investigation depth	25–35 m below ground level
NEHRP site class range in Stoke	C (stiff) to D (medium) depending on fill

Frequently asked questions

What does a MASW survey cost in Stoke-on-Trent?

A single-line MASW survey with Vs30 reporting in the Stoke-on-Trent area typically falls between £1,430 and £2,140, depending on access conditions and the number of spreads. Sites with heavy vegetation, steep slopes, or traffic management requirements push toward the upper end. We can usually quote within a day of seeing the site plan and a brief description of the ground conditions.

How long does it take to get the Vs30 results?

Fieldwork for a single MASW spread takes about two to three hours on a clear, accessible site. Processing and inversion are normally completed within three working days. The final report, including the Vs-depth plot and the site class letter, is issued inside a week. We can accelerate that timeline for urgent planning-condition deadlines if arranged in advance.

Can MASW work on Stoke-on-Trent's tarmac and concrete surfaces?

Yes, with the right coupling. We plant the geophones on small sandbags or use base plates with spikes where the surface allows. Hardstandings actually help by reducing near-surface attenuation. The main constraint is buried services under the spread, which we check against utility plans before setting out the line.

Which site class does Stoke-on-Trent usually fall into?

There is no single answer. On the boulder clay ridges around Hanley and Newcastle-under-Lyme fringe, we often measure Vs30 values in the 360–500 m/s range, placing the site in Class C. Down in the valley where alluvium and colliery fill dominate, Vs30 can drop to 180–280 m/s, which is Class D. That is exactly why a site-specific measurement matters: two plots half a mile apart can sit on different seismic design spectra.
